Orvibo Smart Home MixSwitch Defy Series, Smart Panel App

Orvibo Smart Home MixSwitch Defy; Smart Switch Control Zigbee, supported matter smart home

A love letter to intelligent users in the whole house, the industry's first dual-screen intelligent voice switch. The magic button design makes you want to press it, and the touch is like a skin kiss; The original MixCtrl 2.0 technology is applied, and the key function is freely defined; Built-in human proximity sensor, sensing bright screen.

Basic parameters of MixSwitch Defy

1. Product size: L92.5 * H86 * W12.5mm (length * height * thickness), bottom box thickness: 26.4mm
2. Power supply method: 220V zero fire power supply
3. Load path: 3
4. Maximum load: L1, L2 ≤ 400W/path, L3 ≤ 200W/path
5. Communication protocol: Wi Fi/Zigbee 3.0
6. Memory: 512M+512M
7 IPS touch screen: 2.41 "
8. Microphone: dual Microphone array
9. Speaker: 1W
10. Function: remote control of voice and scene APP can be achieved, key function can customize the scene or dual control function, infrared control and human proximity sensing can be lit

Reserved plan

1. Reserve 1 standard concealed bottom box with a depth of ≥ 5cm;
2. Must reserve a light control zero line;
3. Lighting circuit ≤ 3 circuits;
4. The center distance between adjacent bottom boxes is 86.3mm.
